General Data
• Battery Type: LiFePO4 • Nominal Battery Energy: 5.12kWh • Nominal Capacity: 100Ah • Nominal Voltage: 51.2V • Operating Voltage: 44.8V–57.6V • Recommended C Rate: 0.5C • Recommended Charge/Discharge Current: 50A • Maximum Power Charge Current: 75A • Maximum Power Discharge Current: 100A • Peak Power Charge/Discharge Current: 110A (15s) • Depth of Discharge: 85% • Charging Temperature Range: 0°C to 55°C • Discharging Temperature Range: -20°C to 55°C • Communication: CAN/RS485/RS232 • Cycle Life: >6000 Cycles • Protection Level: IP20 • Warranty: 10 Year • Expansion: 50 Units in Parallel • Usage: Off-grid and hybrid setups • Certification: UN38.3 / CE-EMC / IEC62619 / CEl-021
This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. SunVista Energy Distribution will not be held liable for any product malfunctions due to incorrectly installed systems.
