Battery Input Data
• Battery Type: Li-Ion • Battery Voltage Range: 160VDC to 800VDC • Maximum Charging Current: 50A + 50A • Maximum Discharging Current: 50A + 50A • Number of Battery Input: 2 • Charging Strategy for Li-Ion Batteries: Self-Adaption to BMS
PV String Input Data
• Maximum DC Input Power: 65000W • Maximum DC Input Voltage: 1000VDC • Startup Voltage: 180VDC • MPPT Voltage Range: 150VDC to 850VDC • Full load DC voltage range: 450VDC to 850VDC • Rated DC Input Voltage: 600VDC • PV Input Current: 36A + 36A + 36A + 36A • Maximum PV (Isc): 55A + 55A + 55A + 55A • No of MPP Trackers: 4 • Strings per MPP Tracker: 2
AC Output Data
• Rated AC Output and UPS Power: 50000W • Maximum AC Output Power: 55000W • AC Output Rated Current: 75.8A / 72.5A • Maximum AC Current: 83.3A • Maximum Continuous AC Passthrough: 150A • Peak Power (Off Grid): 1.5 times of rated power, 10S • Generator Input: 75.8A • Smart Load: 150A • AC Couple Current: 75.8A • Power Factor: 0.8 Leading to 0.8 Lagging • Output Frequency and Voltage: 50/60Hz; 3L/N/PE, 220/380VAC, 230/400VAC • Grid Type: Three Phase
Environment Limit
• Operating Temperature Range: -40°C to 60°C • Cooling: Smart Cooling (<45 dB) • Communication with BMS: RS485/CAN • Ingress Protection: IP65 • Safety Certification: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. SunVista Energy Distribution will not be held liable for any product malfunctions due to incorrectly installed systems.
